AFS Flyer Full Set Hydrofoil (1500/1800)

AFS Flyer Complete Carbon  - Wingfoil - SUPfoil  - Dock Start/Pump Foil

Experience ultimate fun with the AFS Flyer Complete Carbon Wingfoil. This kit includes screws, covers, and cases to get you started right away. The Flyer foil is expertly designed to assist in your first wing flights without hindering your progress. Its smooth take-off, stability, control, and predictability make it the ideal choice for learning to fly effortlessly. Made from 100% carbon, it promises durability and performance.

Key Features:

• Easy take-off
• Full carbon construction
• Lightweight and maintenance-free
• Plug & play compatibility with the AFS EVO range

Dimensions:

Front Foil Flyer:

• Surface (cm²): 1500 | 1800
• Span (mm): 955 | 1050
• Aspect Ratio: 6.3 | 6.3
• Cord Max (mm): 185 | 205
• Thickness Max (mm): 20 | 22
• Construction: HR Carbon / Corecell
• Weight (kg): TBA | TBA
• Screw Size: M8x20mm Torx 45

Stabiliser:

• Surface (cm²): 245
• Span (mm): 450
• Aspect Ratio: 8.3
• Cord Max (mm): 66.8
• Thickness Max (mm): 8.3
• Construction: Carbon prepreg
• Weight (kg): 0.2
• Screw Size: M6x16mm
• Compatibility: All AFS fuselages

HR Carbon Mast:

• Length (cm): 80
• Cord Min (mm): 135
• Thickness Min (mm): 16
• Screw Size (mast/fuselage): M8x40mm
• Construction: HR Carbon
• Weight (kg): 1.6
• Compatibility: All AFS FUSELINK foils

Fuselage Evo:

• Length: 68 cm
• Construction: Carbon prepreg
• Compatibility: All Fuselink/stabiliser masts

Program: Designed for wing foil and SUP foil, the AFS Flyer is suitable for beginners to experienced freeride/SUP foilers.

The Kit: The Flyer Pack comes with protective padded covers and a screw kit to mount the front foil, stabiliser to mast, and fuselage. It also includes nuts and screws for mounting the foil to the board and a Y-shaped Torx Key driver.

Warranty: All AFS Flyer/EVO products come with a 2-year warranty, subject to the fair usage policy

Tech specs:

All Carbon components 100% Made in France.

Table of use/Tech Spec in photos for more details.

* Weight Tolerance: +/- 8%. All information contained in this web page is subject to change and alteration at any time without notice.

Mast/Fuselage compatible with the following Foils (wings)

Front wing:

Carver 1250
Carver 1500
Carver 1750
Carver 2000
Flyer 850
Flyer 1000
Flyer 1300
Performer 950
Performer 1250
Performer 1450
Performer 1650
Performer 1900

Rear Wing (Stab):

Tracer 200
Tracer 250
Tracer 310
Tracer 440
Performer S160
Performer S190
Performer RS230
Performer RS260
